Air Pump Brushless DC Electric Motor 6000rpm speed pernanent magnet

Minimum Order Quantity : 100 Price : Negotiated The Price
Packaging Details : 100pcs per carton or as request Delivery Time : 10-12 working days
Payment Terms : T/T, D/A Supply Ability : 100000pcs per month
Place of Origin: China Brand Name: SECORE
Certification: CE ROHS Model Number: BLS-2838I

Detail Information

Speed: 6000RPM Or Customized Rated Torque: 210g.cm Or As Request
Continuous Current: 1.07A Or As Request Diameter*Len: 28*38(mm)
Construction: Pernanent Magnet Weight: 78g
Keyword: Brushless Dc Motor, Motor Brushless, Brushless Motor Controller Typical Application: Robot Arm, Electric Valve, Intelligent Curtain, Electric Car
High Light:

6000rpm Brushless DC Electric Motor

,

Air Pump Brushless DC Electric Motor

,

Brushless air pump dc motor

Product Description

6000rpm Brushless Dc Electric Motor With Performance Customization For Air Pump



Specifications :



1. Structure: 6N4P Inner runner rotor + ball bearing

2. Diameter * Length: Φ28* 38mm

3. Shaft Dia: 2.3mm

4. Rated Voltage:12V,24V

5. Endplay: 0.3mm

6. Lifetime: 20000H min

7. Phase: 3

8. Rotation: CW/CCW controllable

Air Pump Brushless DC Electric Motor 6000rpm speed pernanent magnet 0

MODEL VOLTAGE NO LOAD AT MAXIMUM EFFICIENCY STALL
OPERATING
RANGE
RATED SPEED CURRENT SPEED CURRENT TORQUE OUTPUT TORQUE CURRENT
r/min A r/min A g.cm W g.cm A
BLS2838I-V1 6V~12V 7.4V 5348 0.18 4357 0.778 84.7 3.772 444.9 3.394
BLS2838I-V2 8V~16V 12V 9226 0.26 7346 0.922 89.8 6.782 447.5 3.685
BLS2838I-V3 8V~26V 24V 8205 0.08 6823 0.416 87.6 6.072 512.3 2.027



What are main criterias for selecting an electric motor?



1. You should choose the types of electric motors ( AC Universal Motor, Brushless DC Motor, Brushed DC Motor, Gearbox Motor )

2. In order to select between above groups, it is necessary to determine the type of application required

3. Depending on the movement your require, specifications and size of the motor are necessary as well (  power, torque, speed, dimension, industrial environment etc )

4. Finally, energy efficiency has become an important factor to take into account when selecting a motor:



If there is no suitable specifications, it can be customized according to actual needs.



some of Our customers



Air Pump Brushless DC Electric Motor 6000rpm speed pernanent magnet 1



Air Pump Brushless DC Electric Motor 6000rpm speed pernanent magnet 2

Brushless DC ELectric Motor-Typical Application



-Office apparatus and medical devices
• Printer, Copier, Projector, Shredder
• Sphygmomanometer

- Power tool and fitness equipment

• Electric screwdriver, Electric hydraulic pliers, Electric scissors,
• Fascia gun, massage chair, treadmill
-Household appliances and personal care
• Air purifier, smart toilet, hair dryer, hair curler
• Blender, sweeper, window cleaner, small household appliances
