Vacuum Cleaner24 Volt 350 Watt BLDC Motor , 100000RPM Light Weight Electric Motor BLDC

Minimum Order Quantity : 500 Price : Negotiated The Price
Packaging Details : 500pcs per carton or as request Delivery Time : 10-12 working days
Payment Terms : T/T, D/A Supply Ability : 100000pcs per month
Place of Origin: Guangdong Brand Name: SECORE
Certification: CE ROHS Model Number: BLP-40150

Detail Information

Speed: 100000rpm Or As Request Input Power: 350W At Max Efficiency
Voltage: 24V Dc Commutation: Brushless
Product Name: 100000rpm Bldc Motor, 24V 350w Brushless Motor Typical Application: Vacuum Cleaner, Vacuum Robot, Sputum Suction, Air Suction
High Light:

24 volt 350 watt bldc motor

,

100000rpm 24 volt 350 watt bldc motor

,

350 watt electric motor bldc

Product Description

High Suction Vacuum Cleaner 100000RPM BLDC Motor With Light Weight

Main features:

Voltage:24(optianal)
Power:350w
Speed:100000±10%

High Speed, High Efficiency, Long Life, Light Weight, Customizable



size Φ70*68mm
Shaft Diameter ( customizable ) Φ5mm
Rated Voltage 24v dc
Input Power at Max-efficiency 350w

Speed rpm at max-efficiency 100000±10%rpm
Max efficiency 40%
Max air suction 18Kpa
Max air flow 24dm³/s
noise 96db(100cm)
Life ≥1000h


 Vacuum Cleaner24 Volt 350 Watt BLDC Motor , 100000RPM Light Weight Electric Motor BLDC 0
The Vacuum Cleaner Motor (24V), designed for a famous company, provides the ideal speed for sputum suction, with high speed, long life, high efficiency and other advantages.


What we make?



Secore provides custom engineering to design gear motors utilizing various motor type ( brushless DC motor, brushed DC motor, universal motor and other motors),integrated control & sensing, gear type(spur & helical, worm and planetary) and gearbox material to meet customers' expectation.


Vacuum Cleaner24 Volt 350 Watt BLDC Motor , 100000RPM Light Weight Electric Motor BLDC 1Vacuum Cleaner24 Volt 350 Watt BLDC Motor , 100000RPM Light Weight Electric Motor BLDC 2

TO BE TAILORED


1. Select the correct voltage, expected performance of the motor

2. Confirm the peak current of the brushless drive.

3. Define the working environment (such as temperature, high humidity, etc.).

4. The requirement of power supply insulation.

5. The outer diameter and height of the motor, the diameter of the output shaft, whether it needs to be equipped with a reducer and other related parts.


If there is no suitable specifications, it can be customized according to actual needs.

Some of our customers:

Vacuum Cleaner24 Volt 350 Watt BLDC Motor , 100000RPM Light Weight Electric Motor BLDC 3

Typical Application:



-Office apparatus and medical devices

• Printer, Copier, Projector, Shredder, fax ( paper cutter ), computer peripheral, lifting socket etc.

• breath machine, medical cleaning pump, medical ventilator, medical bed, dental instrument, surgical robot etc

- Power tool and fitness equipment

• Electric screwdriver, Electric hydraulic pliers, Electric scissors,

• Fascia gun, massage chair, treadmill

-Household appliances and personal care

• Air purifier, smart toilet, hair dryer, hair curler, tooth brush, vibration, rubdown machine, foot grinder, facial beauty equipment, eyebrow tweezer, electric threading knife

• Blender, sweeper, window cleaner, small household appliances
