4000rpm Square Bldc Motor Permanent Magnet 12V 24V 26W With 120 Degree Angle
Contact Person : Enya
Phone Number : 86-18988788151
WhatsApp : +8618988788151
Minimum Order Quantity : | 1 | Price : | Negotiated The Price |
---|---|---|---|
Packaging Details : | 1pc per carton or as request | Delivery Time : | 7-10 working days |
Payment Terms : | T/T, D/A | Supply Ability : | 7200pcs per month |
Place of Origin: | China,Guangdong | Brand Name: | SECORE |
---|---|---|---|
Certification: | CE ROHS | Model Number: | BLS110-2000W |
Detail Information |
|||
MOQ: | 1 Piece | Rated Speed RPM: | 3000RPM |
---|---|---|---|
Rated Torque: | 6.38 N.m | Commutation: | Brushless |
Rated Power: | 2000W, 600W/1000W/3000W Optional | Rated Voltage: | 48V, 72V, 310V Optional |
Dimension: | 110mm Diameter * 183mm Length | Construction: | Pernanent Magnet |
Product Type: | 2000W Brushless Motor, PMDC Bldc Motor | Typical Application: | Electric Bicycle, Electric Car, AGV, Electric Vehicle |
High Light: | 2000W Permanent Magnet BLDC Motor,Permanent Magnet BLDC Motor 3000RPM,ROHS 3 Phase Brushless Motor |
Product Description
2000W 3 Phase Permanent Magnet BLDC Motor With Controller For Electric Vehicle
SPECS / Continuous rating for 110mm frame 2000W brushless motor
Model number | Voltage V | Power W | Rated speed rpm |
Rated current A |
Rated torque N.m |
No-load speed rpm |
No-load current A |
Peak Torque N.m |
电机型号 | 电压 V | 功率 W | 额定转速 rpm | 额定电流 A | 额定转矩 N.m | 空载转速 rpm | 空载电流 A | 最大转矩 N.m |
BLS110-2000W-4830 | 48 | 2000 | 3000 | 52.09 | 6.38 | 3300 | <16.2A | 19.2 |
BLS110-2000W-31030 | 310 | 2000 | 3000 | 8.07 | 6.38 | 3300 | <2.31A | 19.2 |
Diagram of the 110mm 2000W brushless dc motor
Rated operating torque: the rated torque of the motor at different speeds, which can run for a long time under this torque;
Continuous operating area: at different speeds, the motor runs continuously in this corresponding interval;
Instantaneous maximum torque: the maximum torque of the motor starting and the instantaneous impact load; when this torque is exceeded, it will cause the overcurrent protection of the driver and cause the shutdown;
Short-term operating area: when the motor rotates at different speeds, it can run at a short speed within this torque range. It will heat the motor if long time running, which may cause burn-in or driving the overheating protection, leading to shutdown;
Dimension:
