Scooter Rc Drone Brushless Motor , Aeromodelling Helicopter Toy Motor

Name: Scooter Rc Drone Brushless Motor , Aeromodelling Helicopter Toy Motor
Brand: SECORE
SKU: BLS-5045
Price: 1.00 USD
Availability: InStock
Rating: 4.9 (148 reviews)

Minimum Order Quantity :	20	Price :	Negotiated The Price
Packaging Details :	50pcs per carton or as request	Delivery Time :	10-12 working days
Payment Terms :	T/T, D/A	Supply Ability :	10000pcs per month

Place of Origin:	Shenzhen	Brand Name:	SECORE
Certification:	ISO9001	Model Number:	BLS-5045

Detail Information
Work Voltage:	11.1V-36V	Motor KV:	270KV-320KV Or Custom
Free Load Current:	1.5A-1.6A	Rated Torque:	1-2.5N.m
Max Power:	2300W	Output Shaft:	6*30mm
Motor Dimension:	50*48mm	Typical Application:	Skateboard, Scooter, E-scooter
High Light:	Outer Rotor BLDC Motor for Skateboard , Outer Rotor BLDC Motor for Scooter , Aeromodelling Helicopter Toy Motor

Product Description

Scooter Rc Drone Oxygen-free Brushless Motor Aeromodelling Helicopter Toy Motor Customization

Specification of Secore BLS5045 Brushless outrunner Motor for Aeromodelling / helicopter toy :

	Product name	RC aircraft motor, aeromodelling motor
	Model #	BLS-5045
	Rated voltage	11.1v-36v
	Diameter*Length	50*45MM
	Rated power	2300W
	hall angle	60
	Poles	14P
	Weight	0.33kg

Features:

Top and bottom covers: 6063-T6 aluminum alloy, Insulating, non-conducting, anodized, very fine heat-resistance.

Case: Made of electroplating steel pipe, featured corrosion resistance, high wear resistance.

Magnet material: NdFeB N45SH, 14 poles, strong magnetism.

Copper wire: high temperature resistance and high purity oxygen-free copper wire, can withstand 220 ℃ temp.

Silicon steel: thickness can be 0.2mm, the thinner the silicon wafer, the less motor consumption
